Transducer | Condenser |
Polar Pattern | Omnidirectional |
Frequency Response | 20 Hz to 20 kHz |
Sensitivity | 5 mV/Pa ± 2.5 dB (free field, no load, 1 kHz) |
Nominal Impedance | 1 kOhm |
Minimal Terminating Impedance | 4.7 kOhms |
Equivalent Noise Level | A-weighted (DIN IEC 651) 26 dB CCIR-weighted (CCIR 468-3) 39 dB |
Maximum Sound Pressure Level (SPL) | 142 dB (1 kHz) (THD = 1 %) |
Power Supply | 18 kOhms/ 7.5 V |
Supply Current | Approximately 250 µA |
Connector | 1/8″ (3.5 mm) locking |
Cable Length | 5.25′ (1.6 m) |
Low Frequency Roll-Off | No |
Microphone Diameter | 0.19″ (4.8 mm) |
Weight | 0.04 oz (1 g) |
